Lens Ring Joint Gasket
Kaxite sealing supply & manufacturer Lens Ring Joint Gasket exporting to all the world. If you need Lens Ring Joint Gasket, please feel free to contact us for quotation.
-
Double Jacket Gasket
Kaxite sealing supply & manufacturer Double Jacket Gasket exporting to all the world. If you need Double Jacket Gasket, please feel free to contact us for quotation.
-
Corrugated Gaskets
Kaxite sealing supply & manufacturer Corrugated Gaskets exporting to all the world. If you need Corrugated Gaskets, please feel free to contact us for quotation.
-
PTFE Envelope Gasket
Kaxite sealing supply & manufacturer PTFE Envelope Gasket exporting to all the world. If you need PTFE Envelope Gasket, please feel free to contact us for quotation.
-
Rubber Sheet
Kaxite sealing supply & manufacturer Rubber Sheet exporting to all the world. If you need Rubber Sheet, please feel free to contact us for quotation.
Modified PTFE Sheet
Modified PTFE Sheets are in order to meet the needs of customers to different working conditions, and reduce the cost. Kaxite research and design the modified ptfe sheets.
| Kaxite Code | MF4350 | MF4354 | MF4351 | MF4353 |
| Color | Fawn | Blue | Off-white | Black |
| Photos | ||||
| Composition | PTFE with silica | PTFE with glass microspheres | PTFE with barium sulfate | PTFE with graphite |
|
Temperature Minimum Cont. max. |
-268  +260
|
-268 +260
|
-268 +260
|
-268 +260
|
| Pressure bar | 75 | 55 | 55 | 75 |
| Sealability cm3/s (GB/T9129-2003) | < 1 x 10-3 | < 1 x 10-3 | < 1 x 10-3 | < 1 x 10-3 |
| Creep Relaxation % ASTM F38 | 20 | 35 | 18 | 35 |
| Compressibility Range % ASTM F36-99 | 10~15 | 25~40 | 5~12 | 7~19 |
| Recovery % ASTM F36-99 | > 21 | >25 | >35 | >35 |
| Tensile Strength N/mm2 ASTMF 152-95 | 13 | 12 | 11 | 11 |
| Flammability | Will not support flame | |||
| Bacterial Growth | Will not support | |||
Benefits:
> Reduced creep relaxation;
> Chemical resistant;
> Cost saving;
> Tighter seal.
Modified PTFE sheets improved performance over conventional PTFE, Reduced product loss and emissions. Excellent bolt torque retention, unique manufacturing process minimizes cold flow problems typical of skived and expanded PTFE Sheets. Withstands a wide range of chemicals for extended service life in a wide variety of applications.
Supplied Sizes:
60'' x 60'' , 70'' x 70'', etc
Thickness: 1/16'', 1/8'', etc
